Mini 20mNm NEMA 8 Stepper Motor 0.6A Casun Stepper Motor For Beauty Equipment

Mini 20mNm NEMA 8 Stepper Motor 0.6A Casun Stepper Motor For Beauty Equipment

Nazwa marki:	Casun
Numer modelu:	20SHD0501-20
MOQ:	1 szt
Cena:	$5.94-$8.6
Warunki płatności:	D/A, T/T, L/C, D/P
Możliwość zaopatrzenia:	40000+szt.+miesiąc

Informacje szczegółowe

Opis produktu

Informacje szczegółowe

Miejsce pochodzenia:

Chiny

Orzecznictwo:

CE,ROSH,ISO

Krok anioła:

1,8°

Trzymanie momentu obrotowego:

20mNm

Aktualny:

0,6A

Długość silnika:

33mm

Wał:

Okrągły wał o długości 10 mm

Dostosowane:

Silnik można zaprojektować i wyprodukować na zamówienie.

Szczegóły pakowania:

Karton: 36x29x14cm

Podkreślić:

0.6A Casun Stepper Motor

Mini 20mNm NEMA 8 Stepper Motor

Casun NEMA 8 Stepper Motor

Opis produktu

20x20x33mm 0.6A Casun Stepper Motor Nema 8 Mini Stepper Motor For Medical beauty equipment

Motor Specifications

Step Angel	1.8 °
Fram Size	20 mm
Number of Phase	2 Phase
Rated Current	0.6 A
Holding Torque	20 mN.m
Resistance	5.8 ohm
Inductance	1.5 mH
Rotor Inertia	2.5 g-cm²
Motor weight	0.07 kg
Number of leads	4
Connection	Bipolar

Appearance

Dimensions

Torque Curves

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get a quote" button below to tell us your requirements.
