10mNm 4 Wire Bipolar Stepper Motor 5V 0.24A Nema 8 Motor 20x20x25mm

10mNm 4 Wire Bipolar Stepper Motor 5V 0.24A Nema 8 Motor 20x20x25mm

Nazwa marki:	Casun
Numer modelu:	B20SHD4701-14P
MOQ:	1 szt
Cena:	$5.94-$8.6
Warunki płatności:	D/A, T/T, L/C, D/P
Możliwość zaopatrzenia:	40000+szt.+miesiąc

Informacje szczegółowe

Opis produktu

Informacje szczegółowe

Miejsce pochodzenia:

Chiny

Orzecznictwo:

CE,ROSH,ISO

Krok anioła:

1,8°

Trzymanie momentu obrotowego:

10mNm

Aktualny:

0,24A

Długość silnika:

24,8 mm

Wał:

Okrągły trzonek o długości 14 mm

Dostosowane:

Silnik można zaprojektować i wyprodukować na zamówienie.

Szczegóły pakowania:

Karton: 36x29x14cm

Podkreślić:

10mNm 4 Wire Bipolar Stepper Motor

4 Wire Bipolar Stepper Motor 5V

5V 0.24A Nema 8 Motor

Opis produktu

Nema 8 Bipolar 1.8deg 10mN.m (1.42oz.in) Stepper Motor 0.24A 5.04V 20x20x25mm 4 Wires

Motor Specifications

Step Angel	1.8 °
Fram Size	20 mm
Number of Phase	2 Phase
Rated Current	0.24 A
Holding Torque	10 mN.m
Resistance	21 ohm
Inductance	5 mH
Rotor Inertia	2 g-cm²
Motor weight	0.08 kg
Number of leads	4
Connection	Bipolar

Appearance

Dimensions

Torque Curves

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get a quote" button below to tell us your requirements.
