NEMA 17 Stepping Motor 424240mm with 4 wire 1.0A for 3D Printer CMM

NEMA 17 Stepping Motor 424240mm with 4 wire 1.0A for 3D Printer CMM

Nazwa marki:	Casun
Numer modelu:	42SHD0221-24B
MOQ:	1 szt
Cena:	$3.14-$5
Warunki płatności:	D/A, T/T, L/C, D/P
Możliwość zaopatrzenia:	40000+szt.+miesiąc

Informacje szczegółowe

Opis produktu

Informacje szczegółowe

Miejsce pochodzenia:

Chiny

Orzecznictwo:

CE,ROSH,ISO

Krok anioła:

1,8°

Trzymanie momentu obrotowego:

300mNm

Aktualny:

1.2A

Długość silnika:

40mm

Wał:

Płaski wał frezujący o długości 24 mm

Dostosowane:

Silnik można zaprojektować i wyprodukować na zamówienie.

Szczegóły pakowania:

Karton: 36x29x14cm

Podkreślić:

4 wire NEMA 17 Stepping Motor

40mm NEMA 17 Stepping Motor

1.0A NEMA 17 Stepping Motor

Opis produktu

The NEMA 17 stepper motor is compatible with various controllers and drivers, providing a high degree of flexibility.

Used for precise adjustment and positioning, such as printing head positioning, laser head positioning for optical disc drives, etc.

Features:

Bipolar or unipolar versions available
Hybrid stepper construction
Delivering high torque and accuracy
CE and RoHS approved
Supply “numerous international certifications” for advanced technology and electronics industry equipment

Motor Specifications

Step Angel	1.8 °
Fram Size	40 mm
Number of Phase	4 Phase
Rated Current	1.2 A
Holding Torque	300 mN.m
Resistance	3.2 ohm
Inductance	3.0 mH
Rotor Inertia	57 g-cm²
Motor weight	0.24 kg
Number of leads	6
Connection	Bipolar

Appearance

NEMA 17 Stepping Motor 42*42*40mm with 4 wire 1.0A for 3D Printer CMM 0

Dimensions

Operating Specifications

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Torque Curves

Submodels

Model	Holding Torque	Step Angle	Motor Length	Type of Shaft	Rated Current
42SHD4950	0.13N.m	1.8°	20mm	D Shaft-20mm	1.0A
42SHD4003	0.26N.m	1.8°	34mm	D Shaft-20mm	0.4A
42SHD0261	0.45N.m	1.8°	40mm	D Shaft-20mm	1.68A
42SHD4425	0.59N.m	1.8°	48mm	D Shaft-24mm	2.0A
42SHD4813	0.8N.m	1.8°	60mm	D Shaft-24mm	2.1A

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder	Brake	Gearbox	Shaft

Please click the "Get a quote" button below to tell us your requirements.
