550mN.M 2 Phase 3.0V DC Nema 17 Hybrid Stepper Motor 42x42mm

550mN.M 2 Phase 3.0V DC Nema 17 Hybrid Stepper Motor 42x42mm

Nazwa marki:	Casun
Numer modelu:	42SHD0437-24BH
MOQ:	1 szt
Cena:	$3.14-$5
Warunki płatności:	D/A, T/T, L/C, D/P
Możliwość zaopatrzenia:	40000+szt.+miesiąc

Informacje szczegółowe

Opis produktu

Informacje szczegółowe

Miejsce pochodzenia:

Chiny

Orzecznictwo:

CE,ROSH,ISO

Krok anioła:

1,8°

Trzymanie momentu obrotowego:

550mNm

Aktualny:

1,68A

Długość silnika:

48 mm

Wał:

Płaski wał frezujący o długości 24 mm

Dostosowane:

Silnik można zaprojektować i wyprodukować na zamówienie.

Szczegóły pakowania:

Karton: 36x29x14cm

Podkreślić:

2 Phase 3.0V DC Nema 17

Hybrid Stepper Motor 42x42mm

550mN.M Nema 17

Opis produktu

The 42mm Hybrid Stepper Motor Series comes in a range of sizes and provides strong holding torque.

Use in conjunction with a microstepping driver to lower vibration and increase step resolution.

Select a base model or ask for a configuration that is unique to you.

Features:

Versions in unipolar or bipolar are offered
For electronic industrial equipment and high-tech industry equipment
Available in variations with a single or double shaft
"Multiple international certifications" are required
Expert manufacturing research and development

Motor Specifications

Step Angel	1.8 °
Fram Size	42 mm
Number of Phase	2 Phase
Rated Current	1.68 A
Holding Torque	550 mN.m
Resistance	1.8 ohm
Inductance	4.5 mH
Rotor Inertia	72 g-cm²
Motor weight	0.38 kg
Number of leads	4
Connection	Bipolar

Appearance

550mN.M 2 Phase 3.0V DC Nema 17 Hybrid Stepper Motor 42x42mm 0

Dimensions

550mN.M 2 Phase 3.0V DC Nema 17 Hybrid Stepper Motor 42x42mm 1

Operating Specifications

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Torque Curves

Submodels

Model	Holding Torque	Step Angle	Motor Length	Type of Shaft	Rated Current
42SHD4950	0.13N.m	1.8°	20mm	D Shaft-20mm	1.0A
42SHD4003	0.26N.m	1.8°	34mm	D Shaft-20mm	0.4A
42SHD0261	0.45N.m	1.8°	40mm	D Shaft-20mm	1.68A
42SHD4425	0.59N.m	1.8°	48mm	D Shaft-24mm	2.0A
42SHD4813	0.8N.m	1.8°	60mm	D Shaft-24mm	2.1A

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder	Brake	Gearbox	Shaft

Please click the "Get a quote" button below to tell us your requirements.
