1.68A Hybrid Stepper Motor NEMA 17 Bipolar Stepper Motor For CNC Router

1.68A Hybrid Stepper Motor NEMA 17 Bipolar Stepper Motor For CNC Router

Nazwa marki:	Casun
Numer modelu:	42SHD4438-24H
MOQ:	1 szt
Cena:	$3.14-$5
Warunki płatności:	D/A, T/T, L/C, D/P
Możliwość zaopatrzenia:	40000+szt.+miesiąc

Informacje szczegółowe

Opis produktu

Informacje szczegółowe

Miejsce pochodzenia:

Chiny

Orzecznictwo:

CE,ROSH,ISO

Krok anioła:

1,8°

Trzymanie momentu obrotowego:

4,2 kg.cm

Aktualny:

1,68A

Długość silnika:

48 mm

Wał:

Okrągły wał o długości 24 mm

Dostosowane:

Silnik można zaprojektować i wyprodukować na zamówienie.

Szczegóły pakowania:

Karton: 36x29x14cm

Podkreślić:

1.68A Hybrid Stepper Motor

Hybrid Stepper Motor NEMA 17

NEMA 17 Bipolar Stepper Motor

Opis produktu

【42SHD4438】 Hybrid Stepper Motor NEMA 17 42×42×48mm 1.68A with 4 wire for CNC equipment

The 42mm Hybrid Stepper Motor Series offers powerful holding torque in a variety of sizes.

Use with a microstepping driver to reduce vibration and achieve higher step resolution.

Choose a baseline version or request your own customized configuration.

Features:

Bipolar or unipolar versions available
Accept contract manufacturing.
Available in single or double shaft versions
Established in China for 12 years and has served more than 800 customers.
Professional research and development manufacturing

Appearance

1.68A Hybrid Stepper Motor NEMA 17 Bipolar Stepper Motor For CNC Router 0

Dimensions

1.68A Hybrid Stepper Motor NEMA 17 Bipolar Stepper Motor For CNC Router 1

Motor Specifications

Step Angel	1.8 °
Fram Size	42 mm
Number of Phase	2 Phase
Rated Current	1.68 A
Holding Torque	4.2kg.cm
Resistance	1.65 ohm
Inductance	37 mH
Rotor Inertia	72 g-cm²
Motor weight	0.38 kg
Number of leads	4
Connection	Bipolar

Operating Specifications

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Torque Curves

Submodels

Model	Holding Torque	Step Angle	Motor Length	Type of Shaft	Rated Current
42SHD4950	0.13N.m	1.8°	20mm	D Shaft-20mm	1.0A
42SHD4003	0.26N.m	1.8°	34mm	D Shaft-20mm	0.4A
42SHD0261	0.45N.m	1.8°	40mm	D Shaft-20mm	1.68A
42SHD4425	0.59N.m	1.8°	48mm	D Shaft-24mm	2.0A
42SHD4813	0.8N.m	1.8°	60mm	D Shaft-24mm	2.1A

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder	Brake	Gearbox	Shaft

Please click the "Get a quote" button below to tell us your requirements.
