0.6A 3.9V Mini Stepping Motor 202030mm Nema 8 For Medical Equipment

0.6A 3.9V Mini Stepping Motor 202030mm Nema 8 For Medical Equipment

Nazwa marki:	Casun
Numer modelu:	20SHD0001-20
MOQ:	1 szt
Cena:	$5.94-$8.6
Warunki płatności:	D/A, T/T, L/C, D/P
Możliwość zaopatrzenia:	40000+szt.+miesiąc

Informacje szczegółowe

Opis produktu

Informacje szczegółowe

Miejsce pochodzenia:

Chiny

Orzecznictwo:

CE,ROSH,ISO

Krok anioła:

1,8°

Trzymanie momentu obrotowego:

15mNm

Aktualny:

0,6A

Długość silnika:

30mm

Wał:

Okrągły wał o długości 15 mm

Dostosowane:

Silnik można zaprojektować i wyprodukować na zamówienie.

Szczegóły pakowania:

Karton: 36x29x14cm

Podkreślić:

0.6A Mini Stepping Motor

3.9V Mini Stepping Motor

202030mm Nema 8

Opis produktu

20x20x30mm NEMA 8 Stepping Motor Manufacturer Mini Motor 18mN.m 0.6A for Medical Equipment

20*20*30mm 0.6A Nema 8 3.9V Stepper Motor Mini Stepping Motor for Medical Equipment

Motor Specifications

Step Angel	1.8 °
Fram Size	20 mm
Number of Phase	2 Phase
Rated Current	0.6 A
Holding Torque	15 mN.m
Resistance	6.5 ohm
Inductance	1.7 mH
Rotor Inertia	2 g-cm²
Motor weight	0.06 kg
Number of leads	4
Connection	Bipolar

Appearance

Dimensions

Torque Curves

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get a quote" button below to tell us your requirements.
