4.4Amp NEMA 23 Stepper Motor 2.3Nm 57X76mm For CNC Casun Stepper Motor

4.4Amp NEMA 23 Stepper Motor 2.3Nm 57X76mm For CNC Casun Stepper Motor

Nazwa marki:	Casun
Numer modelu:	57SHD4834-20BH
MOQ:	1 szt
Cena:	$10.00-$16
Warunki płatności:	D/A, T/T, L/C, D/P
Możliwość zaopatrzenia:	40000+szt.+miesiąc

Informacje szczegółowe

Opis produktu

Informacje szczegółowe

Miejsce pochodzenia:

Chiny

Orzecznictwo:

CE,ROHS,ISO

Kolor:

Czarny

Prąd / faza:

4,4A

Trzymanie momentu obrotowego:

2,3 nm

Dostosowane:

Silnik można zaprojektować i wyprodukować na zamówienie.

Szczegóły pakowania:

Karton: 38x29x18cm

Podkreślić:

4.4Amp NEMA 23 Stepper Motor

57X76mm NEMA 23 Stepper Motor

Opis produktu

Casun stepper motor NEMA 23 motor de passo 2.3Nm 57X76mm for CNC

The Nema23 57MMX57MM Hybrid Open Loop Stepper Motor is a powerful and reliable option for anyone looking for a stepper motor solution for their CNC or SMT machine.
However, users should be aware that the open-loop design may be less precise than the closed-loop version, so it may not be suitable for all applications.

Features:

Bipolar or unipolar versions available
Hybrid stepper construction
Available in single or double shaft versions
CE and RoHS approved
Customizations on request

Dimensions

Motor Specifications

Step Angel	1.8 °
Fram Size	57 mm
Number of Phase	2 Phase
Rated Current	4.4 Amp
Holding Torque	2.3N.m
Resistance	0.765hm
Inductance	2.5mH
Rotor Inertia	460g-cm²
Motor weight	1kg

Operating Specifications

Motor

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Torque Curves

Submodels

Model	Holding Torque	Step Angle	Length	Type of Shaft	Rated Current
42SHD4950	0.13N.m	1.8°	20mm	D Shaft-20mm	1.0A
42SHD4003	0.26N.m	1.8°	34mm	D Shaft-20mm	0.4A
42SHD0261	0.45N.m	1.8°	40mm	D Shaft-20mm	1.68A
42SHD4425	0.59N.m	1.8°	48mm	D Shaft-24mm	2.0A
42SHD4813	0.8N.m	1.8°	60mm	D Shaft-24mm	2.1A

Download

We have the ability to customize motor features such as shafts, winding parameters, installation dimensions, lead wires, and connectors can help to ensure that the motor is a perfect fit for the customer's application. This can lead to improved efficiency, increased reliability, and reduced downtime.

Options:
Encoder | Brake | Gearbox | Shaft

4.4Amp NEMA 23 Stepper Motor 2.3Nm 57X76mm For CNC Casun Stepper Motor 1

Please click the "Get a quote" button below to tell us your requirements.
