Nema 17 Linear Actuator Stepper Motor For Mechanical Transportation

Nema 17 Linear Actuator Stepper Motor For Mechanical Transportation

Nazwa marki:	Casun
Numer modelu:	28SHD4207-188TT
MOQ:	1 szt
Cena:	$9.94-$15
Warunki płatności:	D/A, T/T, L/C, D/P
Możliwość zaopatrzenia:	40000+szt.+miesiąc

Informacje szczegółowe

Opis produktu

Informacje szczegółowe

Miejsce pochodzenia:

Chiny

Orzecznictwo:

CE,ROHS,ISO

Kolor:

Czarny

Aktualny:

0,8A

Trzymanie momentu obrotowego:

80mNm

śruba prowadząca:

Tr5×2

Dostosowane:

Silnik można zaprojektować i wyprodukować na zamówienie.

Szczegóły pakowania:

Karton: 38x29x14m

Podkreślić:

Linear Actuator Stepper Motor

Nema 17 Linear Actuator Stepper Motor

Opis produktu

Nema 17 Linear Actuator Stepper Motor For Mechanical Transportation

The screw mechanical transmission can convert the rotational motion of the motor into linear motion, providing higher torque output.

The NEMA 17 through screw stepper motor can provide more stable and reliable performance.

Features:

Bipolar or unipolar versions available
Hybrid stepper construction
Our engineers will reach out to you within 48 hours to offer the optimal solution
CE and RoHS approved
We provide customized services and are open to contract manufacturing

Dimensions

Motor Specifications

Step Angel	1.8 °
Fram Size	28mm
Number of Phase	2 Phase
Rated Current	0.8Amp
Holding Torque	80mN.m
Resistance	5.8ohm
Inductance	4.1mH
Rotor Inertia	9g-cm²
Motor weight	0.12kg
Lead Screw	Tr5X2
Connection	Bipolar

Operating Specifications

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Shaft Radial Play:0.02Max. (450g-load)

Shaft Axial Play:0.08Max. (450g-load)

Max. radial force:28N (20mm from the flange)

Max. axial force):10N

Torque Curves

Submodels

Model	Holding Torque	Step Angle	Motor Length	Type of Shaft	Rated Current
42SHD4950	0.13N.m	1.8°	20mm	D Shaft-20mm	1.0A
42SHD4003	0.26N.m	1.8°	34mm	D Shaft-20mm	0.4A
42SHD0261	0.45N.m	1.8°	40mm	D Shaft-20mm	1.68A
42SHD4425	0.59N.m	1.8°	48mm	D Shaft-24mm	2.0A
42SHD4813	0.8N.m	1.8°	60mm	D Shaft-24mm	2.1A

Body Length	Diameter of Screw	Pitch	Length of Screw
20 mm 34 mm 40 mm 48 mm 60 mm	5	2	20-1000 mm
		8
	6.35	1.27
		3.175
		6.35
	6.5	3
		6.35
	8	1
		2
		4
		8
		12

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Shaft

Nema 17 Linear Actuator Stepper Motor For Mechanical Transportation 1

Please click the "Get a quote" button below to tell us your requirements.
