4 Wire DC Motor NEMA 17 Step Motor 34mm Body For Security Systems

4 Wire DC Motor NEMA 17 Step Motor 34mm Body For Security Systems

Nazwa marki:	Casun
Numer modelu:	42SHD0034-20BH
MOQ:	1 szt
Cena:	$3.14-$5
Warunki płatności:	D/A, T/T, L/C, D/P
Możliwość zaopatrzenia:	40000+szt.+miesiąc

Informacje szczegółowe

Opis produktu

Informacje szczegółowe

Miejsce pochodzenia:

Chiny

Orzecznictwo:

CE,ROHS,ISO

Krok anioła:

1,8°

Trzymanie momentu obrotowego:

300mNm

Aktualny:

1,0 A

Długość silnika:

34 MM

Wał:

Frezowanie płaskiego wału o długości 20 mm

Napięcie znamionowe:

5.0 V.

Dostosowane:

Silnik można zaprojektować i wyprodukować na zamówienie.

Szczegóły pakowania:

Karton: 36x29x14cm

Podkreślić:

DC Motor NEMA 17 Step Motor

34mm Body NEMA 17 Step Motor

Opis produktu

4 Wire DC Motor NEMA 17 Step Motor 34mm Body For Security Systems

The NEMA 17 stepper motor has a small size but can generate considerable torque.

Scientific instruments, automation equipment, medical equipment, security systems.

Features:

High torque and high precision
Every model of our stepper motor is adaptable to a variety of situations.
Available in single or double shaft versions
Our engineers will contact you within two days to offer the most effective solution
We actively pursue dealers!

Motor Specifications

Step Angel	1.8 °
Fram Size	42 mm
Number of Phase	2 Phase
Rated Current	1.0 A
Holding Torque	300 mN.m
Resistance	5.0 ohm
Inductance	6.2 mH
Rotor Inertia	38 g-cm²
Motor weight	0.2 kg
Number of leads	4
Connection	Bipolar

Appearance

4 Wire DC Motor NEMA 17 Step Motor 34mm Body For Security Systems 0

Dimensions

4 Wire DC Motor NEMA 17 Step Motor 34mm Body For Security Systems 1

Operating Specifications

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Torque Curves

Submodels

Model	Holding Torque	Step Angle	Motor Length	Type of Shaft	Rated Current
42SHD4950	0.13N.m	1.8°	20mm	D Shaft-20mm	1.0A
42SHD4003	0.26N.m	1.8°	34mm	D Shaft-20mm	0.4A
42SHD0261	0.45N.m	1.8°	40mm	D Shaft-20mm	1.68A
42SHD4425	0.59N.m	1.8°	48mm	D Shaft-24mm	2.0A
42SHD4813	0.8N.m	1.8°	60mm	D Shaft-24mm	2.1A

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder	Brake	Gearbox	Shaft

Please click the "Get a quote" button below to tell us your requirements.
