424234mm Stepper Motor Nema 17 1.2A For Medical Equipment With CE

424234mm Stepper Motor Nema 17 1.2A For Medical Equipment With CE

Nazwa marki:	Casun
Numer modelu:	42SHD0063-20BH
MOQ:	1 szt
Cena:	$3.14-$5
Warunki płatności:	D/A, T/T, L/C, D/P
Możliwość zaopatrzenia:	40000+szt.+miesiąc

Informacje szczegółowe

Opis produktu

Informacje szczegółowe

Miejsce pochodzenia:

Chiny

Orzecznictwo:

CE,ROHS,ISO

Krok anioła:

1,8°

Trzymanie momentu obrotowego:

210mNm

Aktualny:

1.2A

Długość silnika:

34 MM

Wał:

Frezowanie płaskiego wału o długości 20 mm

Napięcie znamionowe:

3,24 V

Dostosowane:

Silnik można zaprojektować i wyprodukować na zamówienie.

Szczegóły pakowania:

Karton: 36x29x14cm

Podkreślić:

Stepper Motor Nema 17 1.2A

Stepper Motor Nema 17 CE

Opis produktu

42*42*34mm Motor Stepper Motors Nema 17 For Medical Equipment With CE

Widely used in medical equipment, such as medical robots, surgical instruments, medical injection pumps, etc.

NEMA 17 stepper motors typically come in various specifications and models to meet different engineering needs.

Features:

High torque and high precision
Contract manufacturing accepted
Specializing in drivetrain solutions
Having operated in China for 12 years, we have catered to over 800 customers
Seeking dealers! !

Motor Specifications

Step Angel	1.8 °
Fram Size	42 mm
Number of Phase	2 Phase
Rated Current	1.2 A
Holding Torque	210 mN.m
Resistance	2.7 ohm
Inductance	2.1 mH
Rotor Inertia	38 g-cm²
Motor weight	0.2 kg
Number of leads	4
Connection	Bipolar

Appearance

42*42*34mm Stepper Motor Nema 17 1.2A For Medical Equipment With CE 0

Dimensions

42*42*34mm Stepper Motor Nema 17 1.2A For Medical Equipment With CE 1

Operating Specifications

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Torque Curves

Submodels

Model	Holding Torque	Step Angle	Motor Length	Type of Shaft	Rated Current
42SHD4950	0.13N.m	1.8°	20mm	D Shaft-20mm	1.0A
42SHD4003	0.26N.m	1.8°	34mm	D Shaft-20mm	0.4A
42SHD0261	0.45N.m	1.8°	40mm	D Shaft-20mm	1.68A
42SHD4425	0.59N.m	1.8°	48mm	D Shaft-24mm	2.0A
42SHD4813	0.8N.m	1.8°	60mm	D Shaft-24mm	2.1A

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder	Brake	Gearbox	Shaft

Please click the "Get a quote" button below to tell us your requirements.
