NEMA 11 Mini Stepper Motor 0.67A 95mN.m 44.5mm Body For Medical Equipment

NEMA 11 Mini Stepper Motor 0.67A 95mN.m 44.5mm Body For Medical Equipment

Nazwa marki:	Casun
Numer modelu:	28SHD4401-20B1
MOQ:	1 szt
Cena:	$5.94-$8.6
Warunki płatności:	D/A, T/T, L/C, D/P
Możliwość zaopatrzenia:	40000+szt.+miesiąc

Informacje szczegółowe

Opis produktu

Informacje szczegółowe

Miejsce pochodzenia:

Chiny

Orzecznictwo:

CE,ROSH,ISO

Krok anioła:

1,8°

Trzymanie momentu obrotowego:

95mNm

Aktualny:

0,67A

Długość silnika:

44 mm

Certyfikaty:

CE ISO RoHS

Dostosowane:

Silnik można zaprojektować i wyprodukować na zamówienie.

Szczegóły pakowania:

Karton: 36x29x14cm

Podkreślić:

44.5mm NEMA 11 Mini Stepper Motor

95mN.m NEMA 11 Mini Stepper Motor

0.67A NEMA 11 Mini Stepper Motor

Opis produktu

NEMA 11 stepper motors provide relatively high torque while maintaining a small volume

Suitable for various industries and applications, including medical equipment, laboratory instruments, small robots, precision positioning systems, etc.

Features:

Each model of stepper motor can be suitable for different scenarios
Needed dealers! !
Available in single or double shaft versions
Specialized in R&D and manufacturing
Our engineering team will reach out within 48 hours to deliver the optimal solution

Motor Specifications

Step Angel	1.8 °
Fram Size	28 mm
Number of Phase	2 Phase
Rated Current	0.67 A
Holding Torque	95 mN.m
Resistance	6.8 ohm
Inductance	5 mH
Rotor Inertia	9 g-cm²
Motor weight	0.12 kg
Number of leads	4
Connection	Bipolar

Appearance

Dimensions

Torque Curves

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get a quote" button below to tell us your requirements.
