NEMA 23 Stepper Motor 100mm Body 3.5A 3.5N.m For Industrial Automation

NEMA 23 Stepper Motor 100mm Body 3.5A 3.5N.m For Industrial Automation

Nazwa marki:	Casun
Numer modelu:	57SHD4932-20B
MOQ:	1 szt
Cena:	$3.14-$5
Warunki płatności:	D/A, T/T, L/C, D/P
Możliwość zaopatrzenia:	40000+szt.+miesiąc

Informacje szczegółowe

Opis produktu

Informacje szczegółowe

Miejsce pochodzenia:

Chiny

Orzecznictwo:

CE,ROHS,ISO

Krok anioła:

1,8°

Trzymanie momentu obrotowego:

3200mNm

Aktualny:

3,5A

Długość silnika:

T/T, akredytywa, D/A, D/P, Western Union, MoneyGram

Wał:

Frezowanie płaskiego wału o długości 20 mm

Dostosowane:

Silnik można zaprojektować i wyprodukować na zamówienie.

Szczegóły pakowania:

Karton: 36x29x14cm

Podkreślić:

3.5A NEMA 23 Stepper Motor

3.5N.m NEMA 23 Stepper Motor

100mm NEMA 23 Stepper Motor

Opis produktu

Stepper motors also have small inertia, which can reduce system vibration and impact, and improve system stability.

Suitable for applications that require high thrust or torque, such as automation equipment, machine tools, printing machinery, etc.

Features:

High accuracy and torque
Enjoy a ten-year warranty and complete peace of mind
Expect to hear from our engineers within 48 hours with the best solution for your needs
Custom services available
Based in China for 12 years and has assisted over 800 clients

Motor Specifications

Step Angel	1.8 °
Fram Size	57 mm
Number of Phase	4 Phase
Rated Current	3.0 A
Holding Torque	3200 mN.m
Resistance	2.1 ohm
Inductance	7.5 mH
Rotor Inertia	650 g-cm²
Motor weight	1.3 kg
Number of leads	4
Connection	Bipolar

Appearance

NEMA 23 Stepper Motor 100mm Body 3.5A 3.5N.m For Industrial Automation 0

Dimensions

NEMA 23 Stepper Motor 100mm Body 3.5A 3.5N.m For Industrial Automation 1

Operating Specifications

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Torque Curves

Submodels

Model	Holding Torque	Step Angle	Length	Type of Shaft	Rated Current
57SHD4013-21B	0.6N.m	1.8°	41mm	D Shaft-21mm	1.0A
57SHD4415-21B	1.1N.m	1.8°	54mm	D Shaft-21mm	3.0A
57SHD4816-21B	2.0N.m	1.8°	76mm	D Shaft-21mm	3.0A
57SHD4913-21B	2.5N.m	1.8°	83mm	D Shaft-21mm	3.0A
57SHD4934-20B	3.0N.m	1.8°	100mm	D Shaft-20mm	3.0A

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder	Brake	Gearbox	Shaft

Please click the "Get a quote" button below to tell us your requirements.
