Nema 23 Hybrid Stepper Motor 2N.m High Tough 76mm Body 2.85V Casun Motor CE RoHS for CNC

Nema 23 Hybrid Stepper Motor 2N.m High Tough 76mm Body 2.85V Casun Motor CE RoHS for CNC

Nazwa marki:	Casun
Numer modelu:	F57SHD4816-21B
MOQ:	5 szt
Cena:	$8.1~$9.38
Warunki płatności:	D/A, T/T, L/C, D/P
Możliwość zaopatrzenia:	10000+szt.+miesiąc

Informacje szczegółowe

Opis produktu

Informacje szczegółowe

Miejsce pochodzenia:

Chiny

Orzecznictwo:

CE,ROHS,ISO

Trzymanie momentu obrotowego:

2000 mNm

Woltaż:

2,85 V

Aktualny:

Długość ciała:

76 mm

Waga:

1 kg

Rezystancja fazowa:

0,95 oma ±10% (przy 20 ℃)

Długość wału:

20 mm

Faza:

Klasa izolacji:

Klasa B

Szczegóły pakowania:

Karton: 38x29x18cm

Podkreślić:

76mm Body Hybrid Stepper Motor

Nema 23 Hybrid Stepper Motor

High Tough Hybrid Stepper Motor

Opis produktu

Factory Prices Nema 23 Hybrid Stepper Motor 2N.m High Tough 76mm Body 2.85V Casun Motor with CE RoHS for CNC

Designed for demanding industrial applications, the Casun Nema 23 Hybrid Stepper Motor delivers exceptional 2N.m torque in a compact 76mm body, making it ideal for CNC machines, automated equipment, and high-precision motion systems. With CE & RoHS certification, this motor ensures both performance and compliance for global markets.

Features:

Bipolar or unipolar versions available
Hybrid stepper construction
Available in single- or double-shaft versions
CE and RoHS approved
Customizations on request

Dimensions

Nema 23 Hybrid Stepper Motor 2N.m High Tough 76mm Body 2.85V Casun Motor CE RoHS for CNC 0

Motor Specifications

Step Angel	1.8°
Frame Size	76 mm
Number of Phase	2 Phase
Rated Current	3 Amp
Holding Torque	2000 mN.m
Resistance	0.95 ohm
Inductance	3.6 mH
Rotor Inertia	460 g.cm²
Motor weight	1 kg
Connection	Bipolar

Operating Specifications

Motor

Step Angle: 1.8°

Maximum Temperature: 80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range: 85% or less, non-condensing

Magnet Wire Insulation: Class B 130 deg C

Insulation Resistance: 100M Ohm at 500 VDC

Dielectric Strength: 500 VDC for 1 min

Encoder

Voltage: 5 v

Output: A + A - B + B - Z + Z -

Submodels

Nema 23 Hybrid Stepper Motor 2N.m High Tough 76mm Body 2.85V Casun Motor CE RoHS for CNC 1

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Shaft

Nema 23 Hybrid Stepper Motor 2N.m High Tough 76mm Body 2.85V Casun Motor CE RoHS for CNC 2

Please click the "Get a quote" button below to tell us your requirements.
