1.8 Degree 2 Phase Nema 17 Captive Stepper Motor 34mm Body 0.3N.m For Medical Equipment

1.8 Degree 2 Phase Nema 17 Captive Stepper Motor 34mm Body 0.3N.m For Medical Equipment

Nazwa marki:	Casun
Numer modelu:	42SHD0034-81NP
MOQ:	1 szt
Cena:	$9.68-$14
Warunki płatności:	D/A, T/T, L/C, D/P
Możliwość zaopatrzenia:	40000+szt.+miesiąc

Informacje szczegółowe

Opis produktu

Informacje szczegółowe

Miejsce pochodzenia:

Chiny

Orzecznictwo:

CE,ROSH,ISO

Ołów:

Tr8*1

Ciało:

34 MM

Kąt kroku:

1,8 stopnia

Waga:

0,22 kg

Dostosowane:

Silnik można zaprojektować i wyprodukować na zamówienie.

Szczegóły pakowania:

Karton: 38x29x14m

Podkreślić:

34mm Nema 17 Captive Stepper Motor

0.3N.m Nema 17 Captive Stepper Motor

Opis produktu

The NEMA 17 screw stepper motor can provide very precise motion control, suitable for applications that require high-precision position control.

Through pulse signal control, it is easy to achieve complex motion trajectories.

Features:

Bipolar or unipolar versions available
Hybrid stepper construction
Enjoy a ten-year warranty and purchase with confidence
Our engineers will be in touch within 48 hours to provide the best solution
We specialize in professional drivetrain solutions·

Dimensions

Motor Specifications

Step Angel	1.8 °
Fram Size	42 mm
Number of Phase	2 Phase
Rated Current	1.28A
Holding Torque	300 mN.m
Resistance	5.0 hm
Inductance	6.2 mH
Rotor Inertia	38 g-cm²
Motor weight	0.22 kg
Lead Screw	Tr8X1
Connection	Bipolar

Operating Specifications

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Shaft Radial Play:0.02Max. (450g-load)

Shaft Axial Play:0.08Max. (450g-load)

Max. radial force:28N (20mm from the flange)

Max. axial force):10N

Torque Curves

Submodels

Model	Holding Torque	Step Angle	Motor Length	Type of Shaft	Rated Current
42SHD4950	0.13N.m	1.8°	20mm	D Shaft-20mm	1.0A
42SHD4003	0.26N.m	1.8°	34mm	D Shaft-20mm	0.4A
42SHD0261	0.45N.m	1.8°	40mm	D Shaft-20mm	1.68A
42SHD4425	0.59N.m	1.8°	48mm	D Shaft-24mm	2.0A
42SHD4813	0.8N.m	1.8°	60mm	D Shaft-24mm	2.1A

Body Length	Diameter of Screw	Pitch	Length of Screw
20 mm 34 mm 40 mm 48 mm 60 mm	5	2	20-1000 mm
		8
	6.35	1.27
		3.175
		6.35
	6.5	3
		6.35
	8	1
		2
		4
		8
		12

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Shaft

1.8 Degree 2 Phase Nema 17 Captive Stepper Motor 34mm Body 0.3N.m For Medical Equipment 1

Please click the "Get a quote" button below to tell us your requirements.
